Multi-Industry Loading Case Loader ZXJ-600CT

Side-pushing type Case Loader ZXJ-600CT is equipped with imported electrical components and Siemens PLC + HMI, characteristic of intuitive operation and stable performance, mainly used in food, medicine, cosmetics and other industries. Features

Share:

Quick Changeover
Ubiquitous Precautions
Intuitive Operation
Tight Integration

Product Type

  • Introduction

  • FAQ

  • Video

Features

1. Suitable for automatic grouping, collating and packing products after the middle-of-line packaging.

2. The machine automatically flips and pinpoints cases to ensure precise packing, reassuring users of no case jamming.

3. Widely applied to various specifications of products and cases.

4. Customizable as per users’ specific requirements.

Parameters

Case size (L×W×H)(250-500)×(250-400)×(180-350) mm
Table height600±50mm
Packing speed3-5 cases/min
Power supply220V/50Hz
Power consumption1000W
Air pressure0.6-0.8Mpa
Dimensions (L×W×H)1000×1820×1650mm
Conveying Dimensions (L×W×H)1500×200×880mm
Weight500Kg
Case Loader ZXJ 600CT
